High Zoom Low Zoom |
High Zoom Low Zoom |
| FOV (mm X mm) |
2.8 X 1.8 22.6 X 14.2 |
1.4 X 0.9 11.3 X 7.1 |
| Resolution (mm/pixel) |
0.0015 0.0118 |
0.0007 0.0059 |
| Resolution (lp/mm) |
287.4 32 |
512 64 |
| DOF (mm) |
0.04 5 |
0.02 0.1 |
| WD from front lens (mm) |
97 |
39 |
| Ry Movement range (˚) |
+/- 115 |
+/- 139 |
| Camera |
CMOS 1/1.2" 1936 x 1216 BW |
| Rough size (Ct) |
0.10 to 500 |
| Diamond type |
Rough, blocked or polished |
| Inclusion viewing |
Through flat faces or under immersion Glass |
| Inclusion type |
Any, including VVS, graining, cracks, crystals, etc.. |
| Diamond holding |
Glue assisted for rough and between pins for polish |
| Inclusion plotting |
Auto suggestion and orientation from next direction |
| Auto plotting under iG Cube |
Yes |
| Lighting |
Advance Adaptive Light (iG light included with iG license) |
| Diamond Movements |
Motorized - 5 axes (X,Y, Z, Rx and Ry) |
| Report |
Carbon viewer - example |
| Plan sharing for approval |
Cutwise - My solution example |
| Warranty |
12 months from date of installation |
| Weight (kg) |
40 |
| Dimensions (mm) |
620 (W) X 415 (D) X 655 (H) |
| Power Consumption |
250 W (110-220V 50-60Hz) |
